Timeline and Async

UIFlow supports combining multiple animations / waits into a Timeline, and integrating them with await.

Timeline Effect

UIFlowTimelineEffect consists of multiple UIFlowEffect steps. You can configure:

  • Effects: the effect array for each step.
  • Step Delays: delay before each step starts.
  • Step Wait for Completion: whether to wait for the step to finish before the next one.

Two-stage Scale Punch Example

Timeline configuration

# Configuration:
# Step 0: UIFlowScaleEffect, duration 0.15, from 0.0 to 0.5, punch-out curve
# Step 1: UIFlowScaleEffect, duration 0.15, from 0.5 to 1.0, punch-out curve

This makes the page scale quickly to 0.5, then bounce to full size for a punch-elastic feel.

Async Flow

You can await UIFlow animations directly inside a page:

func _play_open_sequence() -> void:
    await UIFlow.Animator.tween(self, UIFlowTweenProp.MODULATE, Color.WHITE, 0.2).finished
    await UIFlow.Animator.tween(self, UIFlowTweenProp.SCALE, Vector2.ONE, 0.3).finished
    _enable_input()

Combining with Navigation

func _on_start() -> void:
    await UIFlow.Animator.tween(self, UIFlowTweenProp.OPACITY, 0.0, 0.2).finished
    UIFlow.push(GamePage)

Async Navigation and Loading Pages

For large scenes, use push_async() to load the scene on a background thread instead of blocking the frame:

await UIFlow.push_async(InventoryPage)

push_async_with_loading() shows a loading page while the target scene loads, then swaps it for the target automatically:

# Explicit loading page:
await UIFlow.push_async_with_loading(WorldPage, {"level": 3}, null, MyLoadingPage)

# Or configure a default once (used when the parameter is omitted):
UIFlow.Config.loading_page_class = MyLoadingPage
await UIFlow.push_async_with_loading(WorldPage)

Progress protocol. If the loading page implements set_progress(float), the navigator forwards threaded load progress (0.0–1.0, always ending at 1.0 — including cache hits):

class_name MyLoadingPage extends UIFlowPage

@onready var _bar: ProgressBar = $Center/ProgressBar

func set_progress(p: float) -> void:
    _bar.value = p * 100.0

Loading pages are ordinary UIFlowPages, so they are fully skinnable — use your theme, transitions, and layout. See AsyncLoadingPage in the free demo (Timeline & Async demo) for a complete example.

Pre-warming. To make the first push instant, preload scenes ahead of time:

await UIFlow.load_scenes_async([WorldPage, InventoryPage])

Recommendations

  • Prefer UIFlowTimelineEffect resources for complex enter / exit animations.
  • Use inline await for quick one-off animations.
